EN1280
Flash/Anneal Welding Controls
The EN1280 Series Control is a microprocessor-based resistance welding control designed specifically for Flash Welding, Upset Welding, and Anneal applications. The EN1280 can store weld sequence parameters, stored in non-volatile memory, in each of 50 unique schedules. Control is simple to program and operate.
Capabilities:
- Unique Annealing Sequence
- Replaces ENA150 and ENA300
- Program only necessary parameters
- Rotary Input Board – allows for manual adjustment of weld current
Features:
- 50 Unique Weld Schedules
- Standard with 150 and 300A Air Cooled Contactors
- Error Code Display
- Flash Weld Sequence Initiation
- Individual Upset Time and Upset Percent Current
- Anneal Initiation Input
- Manual Current Adjustment
Brochure
