Used WSI Projection-Type Welder
Used WSI projection-type welder FOR SALE [ serial #: 20630 ]. This welder is nearly new!
Used WSI Projection-Type Welder – Stock / Serial #: 20630
Used Equipment Quote
Used WSI projection-type welder FOR SALE [ serial #: 20630 ]. This welder is nearly new! It has a new frame, new air and water system, new air cylinder, new ram and bearings, and a new copper secondary. The 75 KVA weld transformer is remanufactured. The welder looks and operates like new equipment! Unit is completely tested under full power. Carries a NEW equipment warranty!
Stock / Serial #:
20630
Manufacturer Name:
WSI
Type:
Projection Type Welder
Mfg. Model #:
WSI-W1-12-AC-75-5X4-480/1
kVA:
75
Voltage:
480
Phase:
Single
Low Secondary Voltage:
5.7
High Secondary Voltage:
10
# of Tap Switch Positions:
8
Max. Secondary Current:
28,500
Throat Depth to Center of Platens:
12″
Platen Size:
6″ x 6″
Throat Depth to Center of Electrodes:
n / a
Arm Diameter:
n / a
Holder Diameter:
Platen Mounted
Electrode Size:
#2 MT
Cylinder Type:
Air
Cylinder Diameter:
5″
Cylinder Stroke:
4″
Maximum Weld Force, #’s:
1,571
Weld Control Manufacturer:
Entron
Weld Control Mfg. Model #:
EN6001
Disconnect Size:
n / a
Initiation:
2 Stage Foot Switch
General Condition:
This welder is nearly new! It has a new frame, new air and water system, new air cylinder, new ram and bearings, and a new copper secondary. Check out the pictures. The 75 KVA weld transformer is remanufactured. The welder looks and operates like new equipment! Unit is completely tested under full power. Carries a NEW equipment warranty!
Additional Details:
New two stage foot switch installed, LOTO devices installed on air and water inlets, and water flow switch and air pressure switch installed. Welder arms and holders available upon request.
Warranty:
1-Year
Availability:
Immediate
